5.1.5.1.1 Start-up Screen
The HART SmartView starts up displaying the following:
 Black test (all pixels ON)
 Blank test (all pixels OFF)
 Honeywell logo + Software version and checksum
 PV screen or the standby screen
5.1.5.1.2 Menu Screen
By using the [menu] screen of the HART SmartView (
Figure 5-3
) you can view and/or modify settings, or you can send a
specific command to a sensor or a digital I/O board.
MAIN
<
Figure 5-3 The menu screen
