COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 59
954 SmartServo FlexLine
The HCI-BPM module supports the following two protocols
• The Enraf GPU protocol with its records and items (limited);
• The Enraf FlexConn protocol with its entities.
The module can communicate with the following:
• 880 CIU prime
• 858 CIU
• 780 SmartLink
7.3.3.2 Commissioning the HCI-BPM
For a correct functioning of the HCI-BPM module in an instrument
(gauge), the following entities can be set by using either Engauge or
HART SmartView.
☛ By using the following table, check each entity for correctness.
Name Value Range Default Value Explanation
[Baudrate] <1200>
<2400>
<4800>
<1200>
Communication speed
[BPM sensitivity] <1..8> <8>
The sensitivity of the
receiver circuit.
1 = weakest
8 = strongest
[Identification]
8 characters for example,
<TANK1234>
<-------->
Name of a tank or
instrument.
[GPU instrument address] <0..99> <0>
The address of this
instrument for GPU
messages.
Note: Each instrument must
have a unique GPU
address.
[FlexConn instrument address] <0..1899> <0>
The address of this
instrument for FlexConn
messages.
Note: Each instrument must
have a unique FlexConn
address.
[Level units] <Meters>
<Inches>
<Feet>
<Fractions>
<Meters>
The unit in which level-
related GPU records and
items are displayed.
[Temperature units] <Celsius>
<Fahrenheit>
<Celsius>
The unit in which
temperature-related GPU
records and items are
displayed.
