Honeywell FlexLine SmartServo 954 User Manual

COMMISSIONING
60 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
Name Value Range Default Value Explanation
[Pressure units]
<pascal>
<kilo pascal>
<psi small> (2 digits before
separator)
<psi large> (3 digits before
separator)
<pascal>
The unit in which pressure-
related GPU records and
items are displayed.
[Density units]
<kilogram m3>
<degrees API>
<pounds ft3>
<kilogram m3>
The unit in which density-
related GPU records and
items are displayed.
[Decimal separator]
<point>
<comma>
<point>
The decimal separator in
which GPU-related records
and items are displayed.
[Level type]
<innage>
<ullage>
<innage>
The level-related GPU
records and items can be
shown as an innage or
ullage.
Note:
• Innage is the level of the
product measured from
the bottom.
• Ullage is the level of
free space from the roof
till the product.
[Password] <......> 6 characters <ENRAF2>
Password for entering the
protected level.
Note: Some settings reside
under the protected level.
[Function identification] <......> 13 characters <BPM-slave>
The name of the current
function of this module.
This name is visible on the
HART SmartView display.
☛ After having checked/set all before listed entities, make sure you
check the following:
 The [Board Commissioned] and the [BPM slave
Commissioned] entities are <True>.
 The [Board Health] and the [BPM slave Health] entities are
<GOOD>.
