COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 237
954 SmartServo FlexLine
Entity name Entity name
(SmartView)
Description
[Water interface dip] [Water interface dip]
(Product level)
Performs water dip and returns to the default
operation once the water level is found:
o Servo starts searching for water level
o When water level is found it is copied to the Water
Level PV
o Servo returns to interface measurement
dependent on the active operational mode
[CIU Water interface dip] [CIU Water interface
dip]
(Product level)
Performs water dip and stays measuring on water
level until an unlock command is given. Used by the
CIU:
o When CIU sends a GPU “W” record (Water dip)
the BPM module generates the “CIU Water
interface dip” command
o Servo starts searching for water level
o When water level is found it is copied to the Water
Level PV
o Servo stays on water level
o CIU sends a GPU “U” record (unlock)
o Servo returns to interface measurement
dependent on the active operational mode
7.7 Advanced configuration
The servo gauge contains several compensations that can be enabled
or disabled. These compensations improve the accuracy of the level
measurement
Set point compensations
Set point compensations indirectly affect the accuracy of the level
measurement.
Set point compensation Description
Wire weight Compensates for the wire weight. This compensation must always
be enabled.
Unbalance Compensates for the unbalance of the measuring drum and shafts.
Enabling this compensation is highly recommended. This
compensation requires performing a balance test first (refer to
section 0).
This compensation must be enabled for W&M approved
applications!
Density Compensates for changing density of the product. This
compensation is only useful for small area displacers and when the
density of the product is measured (HIMS)
