SYSTEM ARCHITECTURE
Part No.: 4417340 Revision 1 Service Manual 27
954 SmartServo FlexLine
Generic Entities on HART SmartView
From the functions survey screen of the concerning FlexConn module,
the generic entity commands or the commissioning entity can be
selected through the “board” entry.
FII-DO:>
board H C I
Relay 1 G N
Relay 2 G Y
Relay 3 U Y nnn
Relay 4 B Y
Specific Entities on HART SmartView
Selecting a specific function, for instance, “Relay 2”, gives access to the
specific entities for this function.
The specific entities are described in section COMMISSIONING 7
