COMMISSIONING

Part No.: 4417340 Revision 1 Service Manual 107

954 SmartServo FlexLine

7.3.6.9 Board Commissioned Entity

The [Board Commissioned] entity will display either <True> if all

functions are commissioned or <False> if any of the functions are not

commissioned.

☛

If the [Board Commissioned] entity displays <False>, check each

function parameter again. Use the table from 7.3.6.8.

7.3.6.10 Fail-safe Level Application

Following steps include all commissioning-aspects settings for the Fail-

safe level application.

☛

The corresponding jumper of the concerned relay must be in the

Normally Open (NO) state (= default setting).

NOTE: In the Commissioning stage, no jumper setting can be changed

without breaking the compartment screw sealing.

☛

Set [Operation Mode] to [Alarm Mode].

☛

Set [Relay Mode] to <Energized>.

☛

Set [Alarm Mode] to [PV Monitor].

☛

Set [Monitor Board ID] to <board id> of product-level board.

☛

Set [Monitor Board Instance] to <board instance> of related product-

level board.

Set [Monitor Function Instance] to <function instance> of related

product-level board.

☛

Set [Monitor Source] to <PV>.

☛

Set [Monitor Mode] to [Remote].

☛

Set [Remote Threshold Source] to <HH>, <HA>, <LA>, or <LL>.

☛

Set corresponding alarm setting of the related product-level board.

☛

Set [Status Behavior] to <BAD-UNCERTAIN>
