APPENDIX A
290 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
12 Appendix A: Article and part numbers
No. Description Part number
2
Measuring drum 27m incl. shaft and AISI316 wire S0854962
Measuring drum 37m incl. shaft and AISI 316 wire S0854963
Measuring drum 150m AISI 316 wire S0854325
Measuring drum 47m AISI316 0,2mm S0954303
4
Set bolts & rings 6x M6x16 - 854 ATG S0854941
5
Set bolts & rings 3x M10x25 - 854 ATG S0854942
6
Main shaft with magnet - 854 ATG S0854340
7
Round Key for Main shaft S6576001
9
Terminal compartment cover - 854 ATG S0186020
12
Terminal block assembly -954 S0954375
16
Mounting Bracket + Clamping Bracket + Fasteners TBD
17
Fuse set for 854 gauges (10x 250mA 50V + 10x 1A 250V) S0854970
27
Pull Wire S0854151
28
854 Force transducer S0854485
30
Front cover + window - 854 ATG S0854952
Anti-seize paste (Not available for US) S4000015
31
Motor connection board S0894601
32
Motor unit S0854957
35
Set of 2 Ball bearings C 8.0x 22 x 7.0 S2100418
39
Carbon filled PTFE, weight 223 g.; Diameter 25 mm (C/223/CT/025) S0815360
Carbon filled PTFE, weight 223 g.; Diameter 45 mm (C/223/CT/045) S0815343
Carbon filled PTFE, weight 223 g.; Diameter 90 mm (C/223/CT/090) S0815344
Carbon filled PTFE, weight 223 g.; Diameter 110 mm (C/223/CT/110) S0815345
AISI 316; weight 260 g.; max pressure 20 barg; diameter 45 mm (
C/260/S/045)
S0815355
AISI 316; weight 260 g.; max pressure 20 barg; diameter 90 mm (
C/260/S/090)
S0815350
40
Measuring wire INVAR 40 m S0802841
Measuring wire Tantalum 30 m S0802851
Measuring wire AISI 316 30 m S0802801
Measuring wire AISI 316 40 m TBD
Measuring wire AISI 316 43 m TBD
Measuring wire AISI 316 48 m TBD
Measuring wire AISI 316 150 m S0802806
Measuring wire Hasteloy 30 m S0802861
Measuring wire Tungsten 30 m TBD
Measuring wire Tungsten 40 m TBD
Measuring wire Tungsten 43 m TBD
Measuring wire Tungsten 45 m TBD
