Honeywell FlexLine SmartServo 954 - 4.5 Engauge Service Tool

SYSTEM ARCHITECTURE
20 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
Entiti es .
 Health LED
The Health LED (= LE1, the blue circle) indicates the general health
status of the FlexConn module.
Health Status Flashing Pattern
Good
Uncertain
Bad
 2 function LEDs
These LEDS indicate module-specific activities, such as for instance
data being transmitted or received.
