COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 147
954 SmartServo FlexLine
Engauge * Ambient temperature * Tab
NOTE: Some settings for ambient temperature calculations are
shared via the product temperature settings.
☛ The following entities can be set by Engauge or HART
SmartView for a specific functioning of the FII-RTD module in an
instrument. The default values are available after initialization of the
non-volatile memory; so check each entity for its correctness.
Name Explanation Value Range Default
[High High
alarm] [High
Alarm]
[Low Alarm]
[Low Low alarm]
4 Thresholds for activating a related
alarm status in the Primary Value
floating point numbers:
<-x.x .. +x.x>
<+1.0E22>
[Alarm test enable]
Enables (if activated, see next listed
entity) the simulation of one of the 4
alarms for a minute, by simulating the
actual measured Primary Value is
below or above the alarm threshold.
<enable>
<disable>
<disable>
[Alarm test]
Activates and selects at the same time
the Alarm test (if enabled with the
[Alarm test enable] listed before, and the
4 alarm thresholds are
properly set).
[No Alarm]
[High High
alarm] [High
Alarm]
[Low Alarm]
[Low Low alarm]
<No Alarm>
[Function identification]
The name of the current function of
this module. This name is visible on
the HART SmartView.
13 characters
<Ambient temp.>
7.3.8.4.5 Commissioning Check
☛ After having checked/set all before listed entities, make sure
the [Board Commissioned], the [Product temperature
Commissioned], the [Vapour temperature Commissioned],
and the [Ambient Temperature Commis- sioned] entities
are <True>;
the [Board Health], the [Product temperature Health], the
[Vapour temperature Health], and the [Ambient Temperature
Health] entities are <GOOD>.
For viewing the software version, the Engauge Generic tab can be
viewed; also a Reset board command can be issued here.
NOTE: In the HART SmartView situation, the Commissioning flag
must be ‘G’ and the Health flag must be ‘Y’.
