Honeywell FlexLine SmartServo 954 User Manual

COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 217
954 SmartServo FlexLine
7.3.13.2 Safety Shutdown Reason Codes
The Safety Function Status Codes listed below have detail error information in the
output’s Safety Shutdown Reason entity.
Safety Function
Status Code
Safety Shutdown Reason Codes
BOARD
FAILURE
VOLTAGE MON ADC ERROR
Communication with the FII-SIL voltage monitor failed
VOLTAGE MON POWER SUPPLY LO LIM_EXCEEDED
The power supply voltage is below the lower limit.
VOLTAGE MON POWER SUPPLY HI_LIM_EXCEEDED
The power supply voltage is above the upper limit.
VOLTAGE MON LOGIC LO LIM EXCEEDED
The internal voltage VDD1 is below the lower limit.
VOLTAGE MON LOGIC HI LIM EXCEEDED
The internal voltage VDD1 is above the upper limit.
VOLTAGE MON CAN TRANSMITTER LO LIM EXCEEDED
The internal voltage VDD3 is below the lower limit.
VOLTAGE MON CAN TRANSMITTER HI LIM EXCEEDED
The internal voltage VDD3 is above the upper limit.
HARDWARE VERSION VOLTAGE OUT OF RANGE
The FII-SIL hardware version is invalid
FUNCTION
FAILURE
SIL OUTPUT SELF-TEST FAILURE
The output function health diagnostics have failed.
CODE
CHECKSUM
FAILURE
ROM ERROR
The FII-SIL firmware is corrupted.
BOARD
TEMPERATURE
FAILURE
TEMPERATURE MON LO LIM EXCEEDED
The FII-SIL module temperature is below the lower limit
TEMPERATURE MON HI LIM EXCEEDED
The FII-SIL module temperature is above the upper limit
TEMPSENS SPI COMMUNICATION ERROR
Communication with the FII-SIL module temperature sensor failed.
