Balance test
The balance test measures the unbalance and quality of the bearings
over one drum rotation over a configurable number of points. The
resulting unbalance data is used for the unbalance compensation for
both level and density when enabled (refer to sections 7.7.1 and 10.2.3
).
Entity name
Entity name
(SmartView)
Value
Range
Default
Value
Explanation
[Balance test number of
test points]
[BT nr test
point]
(Product
level)
2-32
8
If necessary, change the number
of test points.
Note: When the number has been
changed to a different value the
TII-SRV board needs a reset
before the new setting becomes
active.
The measuring drum unbalance can be measured by the following
procedure:
Entity name Entity name
(SmartView)
Description
[Lock Test] [Lock Test]
(Product level)
The Lock test raises the displacer to the
programmed [lock test motor limit switch level]
position. Then the gauge goes into block mode
(BL). If [Lock test motor limit switch level] is set
higher than [Motor limit switch high] the displacer
stops at the programmed [Motor limit switch
high] position and stays in lock test mode (LT).
[Balance test] [Balance test]
(Product level)
With this command the balance of the measuring
drum is checked. This measurement takes
approximately 5 minutes.
When the balance test is ready, the status on the
display changes from BT to FR and the displacer
level primary value status code changes from
‘Balance Test command active’ into ‘Freeze
command active’.
[Unlock] [Unlock]
(Product level)
Cancel the balance test / freeze command.
