TROUBLE SHOOTING
288 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
Status code
(SmartView)
Description
(Engauge)
Remarks
6162 Drum slip occurred Probable slip of the inner and outer
magnet. This can only be resolved by
entering and exiting maintenance mode.
Please check displacer level before
continuing, there might be an offset of
(multiples of) 11 cm. Refer to sections
7.7.3 and 11.1.
6164 Resetting frequency sensor Frequency sensor failed to start-up but
is recovering. Please wait a short while.
6170 Wire rupture Please check the wire and displacer.
Refer to section 7.7.3.
6172 SAT displacer weight out of
range
SAT failure (refer to section 8.7). Please
check the [SAT raise height up] or check
the displacer weight in air (refer to
sections 9.1.2 and 9.1.3.)
6174 SAT frequency difference too
large
SAT failure (refer to section 8.7). Please
check the bearings (refer to sections
9.1.1 and 9.1.3).
6176 SAT displacer immersed weight
out of range
SAT failure (refer to section 8.7). The
displacer weighs too much in the
product. Please check the [SAT raise
height down].
6178 SAT displacer stuck SAT failure (refer to section 8.7). The
displacer is not able to move freely.
6182 Frequency out of range Sensor frequency larger than 25 kHz.
Please check the frequency sensor if
this error is persistent.
6183 Invalid drum circumference Commissioning error (refer to section
7.4).
6184 Unable to get data from novram
6185 Motor limit high range exceeded The displacer is above the motor limit
high position. Move the displacer down
(refer to chapter 11.1) or adjust the
motor position limits.
Note: please check if the drum
circumference is set to a correct value
(should be approximately 340 mm).
6186 Motor limit low range exceeded The displacer is below the motor limit
low position. Move the displacer up
(refer to chapter 11.1) or adjust the
motor position limits.
Note: please check if the drum
circumference is set to a correct value
(should be approximately 340 mm).
6187 Motor exit data crc corrupted
6188 Motor limits high and low
distance too small
Commissioning error. The motor limits
are too close to each other. The
distance needs to be at least 25 mm.
