Honeywell FlexLine SmartServo 954 User Manual

COMMISSIONING
162 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
Rex AI HART AO Relay Temp
Possible combinations of cards in
FlexLine Gauge
Option 3 1 1 1 1 6 or 14 Option1: HRT-1(HART, Temp & AI as HART
input), HCI-HAO (AO), FII-DO (Relay) - (3
cards)
Option2: HRT-1(HART, & AI as HART input),
FII-RTD (Temp), HCI-HAO (AO) & FII-DO
(Relay) - (4 cards)
Option3: HRT-1(HART & Temp), HRT-2 (AI),
HCI-HAO (AO), FII-DO (Relay) - (4 cards)
SMV card (Display) NOT possible for option
2 & 3.
FII-RTD not possible for option 3.
Option 4 2 0 1 1 6 or 14 Option1: HRT-1 (AI1 & AI2 as HART inputs
and Temp), HCI-HAO (AO), FII-DO (Relay) -
(3 cards)
Option2: HRT-1 (AI1 & AI2 as HART inputs),
HCI-HAO (AO), FII-DO (Relay), FII-RTD
(Temp) - (4 cards)
SMV card (Display) NOT possible for option
2.
Analog Input NOT possible with this combi-
nation
Option 5 1 0 0 1 or 2 6 or 14 Option1: HRT-1 (Temp & AI1 as HART
input),FII-DO (Relay) - (2 car
ds ) Opt ion2:
HRT-1 (AI1),FII-DO (Relay) FII- RTD
(Temp) - (3 cards)
Option 6 0 1 0 1 or 2 6 or 14 Option1: HRT-1 (HART & Temp), FII-DO
(Relay) - (2 cards)
Option2: HRT-1 (HART), FII-DO (Relay), FII-
RTD (Temp) - (3 cards)
Option 7 1 0 1 1 6 or 14 Option1: HRT-1 (Temp & AI1 as HART
input),FII-DO (Relay) & HAO (AO) - (3
cards)
Option2: HRT-1 (AI1),FII-DO (Relay) FII-
RTD (Temp) & HAO (AO) - (4 cards)
SMV card (Display) NOT possible for option
2.
Option 8 0 1 1 1 6 or 14 Option1: HRT-1 (Temp & HART input),FII-
DO (Relay) & HAO (AO) - (3 cards) Option2:
HRT-1 (HART),FII-DO (Relay), FII- RTD
(Temp) & HAO (AO) - (4 cards)
SMV card (Display) NOT possible for option
2.
