COMMISSIONING
220 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
(RO) = read only
Contact 1
Name Value Range Default Value Description
[Contact 1
Health]
(RO)
Status
GOOD
UNCERTAIN
BAD
Status Category
GOOD, ACTUAL VALUE
GOOD, STORED VALUE
UNCERTAIN,
INSTRUMENT
BAD, HARDWARE
FAILURE
BAD, OPERATIONAL
FAILURE
Status Code
See section 7.3.13.1
“Safety Function Status” for
definitions.
Functional health of contact 1.
Any status other than GOOD
will result in a safe state
activation for contact 1.
[Contact 1
safety
function]
< Not Used >
< Overfill >
< Underfill >
< Overfill > The condition of product level
relative to the threshold which
will determine the activation of
a contact 1 safe state, as an
underfill or overfill condition.
Overfill: activation occurs when
the product level is above the
Overfill Threshold.
Underfill: activation occurs
when the product level is
below the Underfill Threshold.
Not Used: contact 1 is
activated in a constant safe
state and does not perform
any function.
[Contact 1
threshold]
< 0 – 3.402823 × 10
38
>
(meters)
< 0 > The product level limit value
for determining an overfill or
underfill condition for contact
1.
To Next Page
