NOTE:
Configurations on the host and RADIUS servers are not shown.
Configuring a RADIUS scheme
1. Create a RADIUS scheme:
a. From the navigation tree, select Authentication > RADIUS.
b. Click Add.
c. On the page that appears, configure a RADIUS scheme:
− Enter the scheme name system.
− Select the service type Extended.
− Select Without domain name from the Username Format list.
d. Click Apply.
2. Configure the primary authentication server in the RADIUS scheme:
a. In the RADIUS Server Configuration area, click Add.
b. Configure the primary authentication server:
− Select the server type Primary Authentication.
− Enter the IP address 192.168.1.2, and enter the port number 1812 .
− Enter name in both the Key field and the Confirm Key field.
c. Click Apply.
Figure 425 Configuring the RADIUS authentication server
3. Configure the primary accounting server in the RADIUS scheme:
a. In the RADIUS Server Configuration area, click Add.
b. Configure the primary accounting server:
− Select the server type Primary Accounting.
− Enter the IP address 192.168.1.2, and enter the port number 1813.
− Enter money in both the Key field and the Confirm Key field.
