36
Figure 21 Setting CE1/PR1 interface parameters (in E1 mode)
Table 18 Configuration items (in E1 mode)
Item Descri
tion
WAN Interface
Select the CE1/PR1 interface to be configured.
Work Mode: E1
Select the E1 work mode.
User Name
Specify the user name for identity authentication.
Password
Display whether a password has been specified for identity authentication.
An empty field indicates that no password is configured.
New Password Specify or modify the password for identity authentication.
TCP-MSS Set the maximum TCP segment length of an interface.
MTU Set the MTU of an interface.
2. In CE1 mode
Figure 22 Setting CE1/PR1 interface parameters (in CE1 mode)
