Indicator Color Name Status
RUN Green Communicati
on status
indicator
● O: The power is abnormal or the
board program is loading.
● Blinking at long intervals: The access
actuator successfully registers with the
ECC800-Pro and the software runs
properly (the indicator blinks at 0.5 Hz,
on for 1s and then
o for 1s).
● Blinking at short intervals: The
communication fails or the access
actuator fails to register with the
ECC800-Pro (the indicator blinks at 4
Hz, on for 0.125s and then
o for
0.125s).
● Blinking: The indicator blinks at super
short intervals for 0.5s (blinking at 10
Hz, on for 0.05s and then
o for 0.05s)
and then turns
o for 0.5s. The cycle
lasts for 5s.
ALM Red Alarm
indicator
● Steady on: A system failure alarm is
generated.
● O: No system alarm is generated.
RF_Z Green Wireless
communicati
on status
indicator
● Steady on: No network parameters
exist, or a network is to be created.
● Blinking at long intervals: A network is
set up, and no node access is allowed
(the indicator blinks at 0.5 Hz, on for
1s and then
o for 1s).
● Blinking intermittently at super short
intervals: The access actuator is
searching for a network (the indicator
blinks at super short intervals for 0.5s
and then turns
o for 0.5s).
Communications Ports
The access actuator provides one DO port (LOCK/GND) and one DI port (GATE/
COM). Table 3-30 lists the LOCK/GND/GATE/COM port pin denitions.
Table 3-30 LOCK/GND/GATE/COM port pin denitions
Item
Description
LOCK/GND
(control
magnetic
LOCK 12V_OUT
ECC800 Data Center Controller
User Manual (for ECC800-Pro) 3 Device Description
Issue 02 (2020-09-07) Copyright © Huawei Technologies Co., Ltd. 35
