D-10
FUNCTION DESCRIPTION
RAMP Selects Ramp as active Wave Shape.
RANDOM Selects Random Data Pattern type in optional BER Meter operation.
RD ONLY Sets or clears Read Only attribute to a file to prevent the file from being deleted or
changed.
RECALL Displays stored trace only.
REF-LIVE The value of current reading is subtracted from the stored value and the result is
displayed. Requires a previously stored trace.
REG Initiates Manual Registration Test.
REGISTN Forces RU selected by PFIX/IDENT to Register and interrogates the ESN.
REP Switch to decoding messages from the repeater. The receiver frequency is
automatically adjusted.
REP SIM Accesses EDACS or MPT 1327 Repeater Simulator screen.
REPEAT Accesses LTR Trunking Option Repeater Simulation.
RESET Resets the current field to zero.
RESTORE Finalizes Recall Operation.
RESULTS Pages through automatic test results.
RESUMERestarts Sweep Function.Returns the COM-120C to normal
operation.
RETURN Exits an application or window and returns to normal operation.
RE-ZERO Sets RF Power Meter to 0 mW referenced to current input at T/R Connector.
RF GEN Selects RF Generator as BER Meter source.
RF POW Selects RF Power Meter input line s input source for meter.
RF REC Selects RF Receiver (either T/R or ANT) as BER Meter input.
ROAM Selects simulated Roam Registration.
ROLL Views the scope trace in a roll mode when selected sweep rate is 100 ms/div or
higher.
RS-232Prints via RS-232 Connector on the COM-120C rear panel.
RST PK Resets Peak Readings displayed to 0.
S=On/Off Toggles SINAD Function ON and OFF.
SAVE Finalizes Storage Operation.
SCAN Accesses Scan pop up window for setting Scan Function parameters. Scans specified
frequencies on Frequency List.
SCOPE Displays abbreviated Scope.
SCP/DVM Selects SCOPE/DVM Connector as input source for meter.
SCROLL Toggles Scroll Function ON and OFF. Highlighted when SCROLL is active.
SDM Sends a textual (SDM2) message to the RU selected by PFIX/IDENT.
