12. P_bar, H_bar – pressure and barometric height.
13. New_GPS is indicator of new update of GPS data (see Table C.6);
14. The low byte is transmitted by first.
Table C.9 The INS message payload at the “INS OPVT2AW” (Orientation, Position,
Velocity, Time, Dual-antenna receiver data, GPS Week) format
Byte
number
0 – 1
2 – 3
4 – 5
6 – 11
12 – 17
18 – 23
24 – 25
26 – 27
28 – 29
Parameter
Heading
Pitch
Roll
GyroX,
GyroY,
GyroZ
AccX,
AccY,
AccZ
MagX,
MagY,
MagZ
USW
Vinp
Temper
Length
2 byte
word
2 byte
sword
2 byte
sword
3
2 byte
sword
3
2 byte
sword
3
2 byte
sword
2 byte
word
2 byte
word
2 byte
sword
Note
Orientation angles,
deg*100
Angular
rates,
deg/s
*KG
Accele-
rations
g*KA
Magne-
tic
fields,
nT/10
Supply
voltage,
VDC*
100
Temper
ature,
ºC*10
Table C.9 (continued)
Byte
number
30 – 33
34 – 37
38 – 41
42 – 45
46 – 49
50 – 53
Parameter
Latitude
Longitude
Altitude
East
speed
North speed
Vertical
speed
Length
4 byte
integer
4 byte
integer
4 byte
integer
4 byte
integer
4 byte
integer
4 byte
integer
Note
deg *1.0e7
deg
*1.0e7
m*100
m/s*100
m/s*100
m/s*100
Table C.9 (continued)
Byte
number
54 – 57
58 – 61
62 – 65
66 – 69
70 – 71
72 – 75
Parameter
Latitude
GNSS
Longitude
GNSS
Altitude
GNSS
Horizontal
speed
GNSS
Track over
ground
GNSS
Vertical
speed
GNSS
Length
4 byte
integer
4 byte
integer
4 byte
integer
4 byte
integer
2 byte
word
4 byte
integer
Note
deg *1.0e7
deg *1.0e7
m*100
m/s*100
deg*100
m/s*100
