Inertial Labs INS-P User Manual

INS
GUI User’s Manual
Inertial Labs, Inc
TM
Address: 39959 Catoctin Ridge Street, Paeonian Springs, VA 20129 U.S.A.
Tel: +1 (703) 880-4222, Fax: +1 (703) 935-8377 Website: www.inertiallabs.com
44
– STD_Vh (m/s) is standard deviation of the odometer noise. Usually its
value is 0.28 m/s.
– k_Sigma_V is residual threshold. Its default value is 10.
See section “10.7. INS operation with odometer” for more details.
Important note: it is necessary to power off / on the INS after changing any of
parameters in the “COM Port 4” field to re-initialize COM4 port.
4.2.6. “Triggers” tab of “Devices options…” window
In the “Triggers” tab the user can set the following parameters (see Fig.
4.17):
 Mark inputs control – allows adjusting processing of mark input
signal that can be used to trigger specific GNSS raw receiver data. See
section “13.2. Processing of mark input signal” for details.
 PPS control fields adjust the pulse-per-second (PPS) signal
generated by GNSS receiver for data synchronization with other devices.
See section “13.1. Control of PPS output signal” for details.
Important note: after applying of any changes in the “Triggers” tab by clicking “OK”
button, it is necessary to switch off, switch on INS unit to restart onboard GNSS receiver.
