Inertial Labs INS-P User Manual

INS
GUI User’s Manual
Inertial Labs, Inc
TM
Address: 39959 Catoctin Ridge Street, Paeonian Springs, VA 20129 U.S.A.
Tel: +1 (703) 880-4222, Fax: +1 (703) 935-8377 Website: www.inertiallabs.com
66
5.1. INS 3D
“INS 3D GUI“ is default variant of the INS visualization in which current
orientation angles of the INS are shown as spatial orientation of an airplane
(see Fig. 5.1). To go to this visualization stile select “INS visualization“
from the “Run“ menu (Fig. 3.3), select on the toolbar, or press F4 button.
Fig. 5.1
Some additional 3D models may be used for visualization of the INS
orientation (see below Section 14. Choice of 3D model for visualization of
the INS orientation).
In opened “INS visualization” tab, four control buttons (active “Start” and
inactive yet: “Stop” ,“Write” ,“Snapshot” , “Start/Stop VG3D clb”
, and “Start/Stop Odometer Clb” ) appear in the left vertical toolbar. If
in the menu “Test Options” the data output method “On Request“ is chosen,
then inactive button “Request” appears.
