Inertial Labs INS-P User Manual

INS
GUI User’s Manual
Inertial Labs, Inc
TM
Address: 39959 Catoctin Ridge Street, Paeonian Springs, VA 20129 U.S.A.
Tel: +1 (703) 880-4222, Fax: +1 (703) 935-8377 Website: www.inertiallabs.com
82
7. Parameters menu
“Parameters” menu enable to work with INS parameters. There are such
items in the “Parameters” menu:
 Load block parameters;
 Read block parameters;
 Restore parameters;
 Save parameters;
 Preset parameters.
7.1. “Load block parameters” and “Read block parameters”
items
These items are used to check operation of appropriate commands of the
INS. But INS GUI software allows more convenient means to load the INS
parameters to the INS nonvolatile memory (see section 7.2).
7.2. Restore parameters
“Restore parameters” command (see Fig. 3.4) is used to quickly load the
INS parameters to the INS nonvolatile memory. When “Restore
parameters” command is selected, or button is clicked, a standard
Windows “Open” window opens; in this window operator selects one of the
previously saved files with .prm extension. Consequently, the parameters
are automatically saved to the INS nonvolatile memory and to the GUI shell.
The same way is used to restore the factory settings of the INS parameters.
In this case you should select original file with .prm extension that comes on
the Flash Drive within a delivery package of the Inertial Labs INS.
INS GUI software checks matching of serial numbers stored in .prm file and
in INS unit. INS GUI software does not allow to restore parameters from
.prm with wrong serial number.
Since INS GUI software version 2.0.46.272 from 2018-05-15 it possible to
restore parameters from .prm file where serial number differs from serial
number of INS unit which is currently connected. But the next warning
