Then you can switch the receiver between previously added models. Click
on the “Choose model button”. You will see the list of available models:
Choose one of these models or click “Cancel” item.
Note: The current model which the receiver uses now is written on the top of the “GNSS
receiver” tab of the “Device options” menu item, see Fig. 4.5.
If you chose one of models in above list the GNSS receiver restarts. Please
wait about 5 – 10 seconds and power off then power on the INS to restart
the INS, too.
Go to the “GNSS receiver” tab of the “Device options” menu item to check
change of the receiver model. Also, please set there the maximum rate of
the GNSS data update supported by chosen model of the GNSS receiver –
in the field “Set measurement rate (Hz)”.
Notes:
1. If you changed the GNSS data rate and clicked “OK” you must to power off then
power on the INS unit to restart the INS,
2. The INS unit controls entered rate of the GNSS data and does not allow to set it larger
than supported by the current GNSS receiver model.
Or click on the “Device Information” in the “Run” menu item to simple check
change of the receiver model.
10.2.2.3. Removing model from the GNSS receiver
Go to the “GNSS receiver” tab of the “Device options” menu item, see Fig.
4.5. Enter full authorization code of model that is removing to seven (or first
six) fields of the “Auth code:”, then click the “Remove” button.
After model is removed the GNSS receiver restarts. Please wait about 5 –
10 seconds and power off then power on the INS to restart the INS.
