Inertial Labs INS-P User Manual

INS
GUI User’s Manual
Inertial Labs, Inc
TM
Address: 39959 Catoctin Ridge Street, Paeonian Springs, VA 20129 U.S.A.
Tel: +1 (703) 880-4222, Fax: +1 (703) 935-8377 Website: www.inertiallabs.com
239
 first alignment angle sets position of the INS longitudinal axis Y relative
to longitudinal axes of the object measured in the horizontal plane of
the object. Clockwise rotation is positive;
 second alignment angle is equal to angle of inclination of the INS
longitudinal axis Y relative to the horizontal plane of the object. Positive
direction is up;
 third alignment angle is equal to inclination angle of the INS lateral axis
X measured around INS’s longitudinal axis. Positive rotation is X axis
moving down.
All angles are set in degrees.
Some examples of the Inertial Labs INS mounting relative the object are
shown on Fig. E.2.
To check correctness of the alignment angles please run the INS using the
Inertial Labs INS GUI.
