SQC-310 Operating Manual
Table 2-6 SQC-310 to EBS-530 wiring chart
SQC-310
Function
EBS-530 Function SQC-310 I/O Connector
(Refer to section 2.8 on
page 2-11 for pinout)
EBS-530
Digital I/O
Connector
Relay: BCD Bit 0
Input: Pattern Select Bit 0 Either pin of relay named
Sourcen_BCD_Bit0
Pin 7
Relay: BCD Bit 1
Input: Pattern Select Bit 1 Either pin of relay named
Sourcen_BCD_Bit1
Pin 2
Relay: BCD Bit 2
Input: Pattern Select Bit 2 Either pin of relay named
Sourcen_BCD_Bit2
Pin 14
Relay: BCD Bit 3
Input: Pattern Select Bit 3 Either pin of relay named
Sourcen_BCD_Bit3
Pin 12
Relay: Used in
Logic Statement
Input: Sweep is turned on if I/O mode
and Interlock inputs are active and logic
statement is true.
Either pin of relay named
Relayn_LSn
Pin 6
Relay Common
Input Common Other pins of
Sourcen_BCD and
Relayn_LSn relays
Pin 1
N/A
Input: Required I/O mode is activated by
continuity between pins 3 and 1. Front
panel pattern selection is disabled when
I/O control mode is active.
N/A Pin 3
N/A
Input: Required Interlock is activated by
continuity between pins 8 and 1. To
protect e-beam coils, use cooling water
on signal to activate this input.
N/A Pin 8
Input: Used in
Logic Statements
Relay: Indicates I/O mode is active and
no errors are present.
Input named
Inputn_LSn&n
Pin 9
Input Common
Relay Common Pin 24 Pin 5
