Inficon SQC-310 User Manual

4 - 14
PN 074-550-P1C
SQC-310 Operating Manual
Table 4-3 Get/Set film parameters
Cmd ID Description Parameters
A1 Sets/Gets the film name.
1 Film Name
A2 Sets/Gets the main film edit
screen parameters.
1P Term
2I Term
3D Term
4 Material #
5 Pocket
6 Tooling
7 Crystal Quality, Rate Dev %
8 Crystal Stability, Single Freq Shift
9 Xtal Fail Mode (obsolete)
10 Crystal Quality, Max Count
11 Crystal Stability, Total +Freq Shift
A3 Sets/Gets the film conditioning
parameters.
1 Ramp1 Power
2 Ramp1 Time
3 Soak1 Time
4 Ramp2 Power
5 Ramp2 Time
6 Soak2 Time
7Idle Power
8Idle Ramp
9 Feed Power
10 Feed Ramp
11 Feed Time
A4 Sets/Gets the deposit controls
parameters.
1 Shutter Delay
2 Capture
3 Control Error (0,1,2)
4 Control Percent
5 Rate Sampling (0,1,2)
6 Sample Accuracy
7 Sample Hold
8 Sample Time
A5 Sets/Gets the sensor controls
parameters.
1 Snsr 1 Crystal Fail Mode
2 Snsr 1 Crystal Position
3 Snsr 1 Backup Sensor
4 Snsr 2 BackupXtalPosition
5 Snsr 2 Crystal Fail Mode
6 Snsr 2 Crystal Position
7 Snsr 2 Backup Sensor
8 Snsr 2 BackupXtalPosition
9 Snsr 3 Crystal Fail Mode
10 Snsr 3 Crystal Position
11 Snsr 3 Backup Sensor
12 Snsr 3 BackupXtalPosition
13 Snsr 4 Crystal Fail Mode
14 Snsr 4 Crystal Position
15 Snsr 4 Backup Sensor
16 Snsr 4 BackupXtalPosition
