Chapter 2: Installation
Power
44/ 526 2.0 Eclipse User Guide
Power
Both the Console and DioCore include two power supplies for
redundancy (A and B). Only one supply is required, however,
we recommend that you connect both power supplies in order
to benefit from automatic redundancy during a live show.
Warning
• Connection of this equipment must be performed in
compliance with the International Electrical Code (IEC
60950) and any additional safety requirements
applicable to your installation.
• The power supply must be earthed. Grounding
connectors are provided on all devices. If the power cord
has a three-pin plug, it will provide sufficient grounding
so long as the AC socket is grounded correctly.
For optimal performance, the earthing network should be free of
noise and all earthing connections must originate from a central
earthing point. It is recommended that you pull an extra earthing
wire from each socket, and connect that directly to the central
earthing point. This is the best way to ground all the devices of
your installation.
Power Consumption & Voltage
The control surface and DioCore can be powered by a voltage
between 90 and 253 volts AC, at 46-63Hz
The maximum power consumption of the DioCore is 300W.
Warning
Only supply the input voltages described.
