Chapter 8: Utilities & Preferences
Linking
Eclipse User Guide 2.0 409/ 526
Linking
Any input, output or VCA channel can be linked to other
channels of the same type.
Two different types of link group are available:
• Channel Linking – links the DSP processing sections
provided by the Sy80 DSP module, see Page 410.
• I/O Linking – links any I/O parameters or processing on
input or output cards, see Page 421.
For example, to link EQ and Dynamics on an input channel you
would use channel linking. But to link the EQ and Dynamics on
a UM8 processed output you would use I/O Linking. The
diagram below summaries the differences:
I/O parameters, on the I/O Cards
DSP parameters, within the channel strip
