INNOVASON Eclipse - Audio Rack; I;O and FX Cards; Options

Technical Data
522/ 526 2.0 Eclipse User Guide
Audio Rack
• Dimensions (H x W x D): 12.2 x 12.3 x 19”
• Weight: 44lb
• Dual redundant power supply
• Power requirements: 300W max
• Operating temperature: 50-90°F
• Eight I/O card slots
• Muxipaire Stage Box if rack equipped with SCoptical card
• DioCore (Ethersound interface) if equipped with ARC card (up to 4 DioCores may be
used simultaneously)
• Supplied with flight case:
o Dimensions (H x W x D): 29 x 20.6 x 24.6”
o Weight: 59.5lb
I/O and FX cards
• All cards operate at a 24-bit resolution and a frequency of 48 KHz (43-49KHz if
platform is synchronised to an external signal)
• SI-8D3: eight mic/line inputs on eight balanced XLRs. Gain is adjustable from -27 to
+63dB.
• DI-8S: four inputs on four balanced XLRs provide eight AES input channels
• DI-8Src: four inputs on four balanced XLRs provide eight AES input channels, each
of which has its own SRC (sample rate converter). Accepts AES signal with a
frequency from 32-56KHz.
• UM-8PO: eight analogue outputs on eight balanced XLRs. Each pair of outputs is
switchable to AES. The eight audio channels are also available as ADAT via a
TOSlink connector. Each output is fully processed including 8-band parametric EQ,
31-band graphic EQ, Gate, Compressor, Delay. Output level from 10.5-22dBu
• FM-8VB: Eight-channel I/O module with, between each I/O, four effects engines,
each of which can receive a VB Audio plug-in. Reverb, Echo, Chorus, Flanger, De-
esser, Compressor, Gate, Multiband compressor, etc.
Options
• Dio AV: AVIOM A-Net Interface
• Dio Madi Es: Ethersound / Madi and Madi / Ethersound converter 64 channels
• Dio 8 Out : 1U Ethersound module, 8 analog balanced outputs
