Chapter 2: Installation
System Connections
Eclipse User Guide 2.0 45/ 526
System Connections
Having installed the control surface and DioCore, it’s time to
connect up the system.
Pre-installed Connections
The system ships with the following pre-installed connections:
• Network link between the Nova and M.A.R.S. control
computers (Ethernet).
• Screen connections (VGA) to the touch-screen.
• Ethersound link between the console (OUT of the DioEs
module) and M.A.R.S IN.
These connections allow you to play back a demo song from
M.A.R.S. without connecting the DioCore. Simply apply power
to the console PSUs and follow the instructions on Page 448.
