Chapter 8: Utilities & Preferences
Linking
Eclipse User Guide 2.0 421/ 526
The Link IO Display
The LINK IO display is used to link I/O parameters or
processing on input or output cards:
For inputs you can link:
• Gain - Analogue gain (SI-8 cards) or Digital trim
• Phantom Power - (SI-8 cards only)
For UM-8 processing outputs you can link:
• Gain (Analogue output level)
• Delay
• Gate
• Compressor
• Parametric EQ and Graphic EQ
Up to 40 input and 40 output Link groups may be created.
Parameters within each group operate as a ganged link. In
other words, adjust one channel to adjust all channels in the
group.
Links between channels are relative. For example, a gain
change from 0dB to +3dB will add 3dB to the gain of all
channels within the link group.
IO Links are saved and recalled from a Page.
