Chapter 4: Getting Started (The Standard Template)
Default Patching
96/ 526 2.0 Eclipse User Guide
Outputs
The stereo Master, Matrix outputs 1-12 and stereo Monitor bus
are patched to the 16 UM-8PO outputs at the rear of the
console. All these outputs feature signal processing provided by
the UM-8 card: Compressor, Gate, Delay, Parametric EQ,
Graphic EQ and output Gain.
The four stereo Auxes (Fader strips 41 to 44) are patched to the
8 UM-8PO outputs in the DioCore. Therefore they also feature
Output processing.
You can view or modify this patching from the PATCH OUT
grid, as described on Page 247:
