8 ADDITIONAL FUNCTIONS DACS-W Operation Manual
8-14
8.4.2.11 Under Weight Output Signal
This item sets the output signal which is output when underweight packs are passed.
Follow this procedure to set the signal parameter.
1. Display the Reject Setting menu.
2. Press or to align the cursor with
"Over Weight Signal".
3. Press .
The Over Weight Signal menu appears.
4. Set the output signal via the ten-key pad.
An asterisk (*) will appear below the set
item.
5. If this item is reset, the asterisk will disappear.
(Setting cleared)
6. Press .
The setting for this parameter will appear on
the Reject Setting menu.
Figure 8-28 Reject Setting Menu
Figure 8-29 Over Weight Signal Menu
1. Display the Reject Setting menu.
2. Press or to align the cursor with
"Under Weight Signal".
3. Press .
The Under Weight Signal menu appears.
4. Set the output signal via the ten-key pad.
An asterisk (*) will appear below the set
item.
5. If this item is reset, the asterisk will disappear.
(Setting cleared)
6. Press .
The setting for this parameter will appear on
the Reject Setting menu.
Figure 8-30 Reject Setting Menu
Figure 8-31 Under Weight Signal Menu
ENTER
▼
▲
SELECT
ITEM
EXIT
[Reject Setting]
* Double Item Rej. Dir. Left
* Proper Weight Signal 1
* Over Weight Signal 2
[Over Weight Signal]
Signal No. : 1 2 3 4 5
Output Pattern : *
No.5 : Reject Buzzer Signal
2
ENTER
▼
▲
SELECT
ITEM
EXIT
[Reject Setting]
* Proper Weight Signal 1
* Over Weight Signal 2
* Under Weight Signal OFF
[Under Weight Signal]
Signal No. : 1 2 3 4 5
Output Pattern :
No.5 : Reject Buzzer Signal
