8.4.2.15 Zero Error Output Signal
This item sets the signal to output when an item is rejected due to zero error occurrence.
Follow this procedure to set the signal parameter.
8.4.2.16 Double Item Output Signal
This item sets the signal to output when an item is rejected due to double item error occurrence.
Follow this procedure to set the signal parameter.
1. Display the Reject Setting menu.
2. Press or to align the cursor with
"Zero Error Signal".
3. Press .
The Zero Error Signal menu appears.
4. Set the output signal via the ten-key pad.
An asterisk (*) will appear below the set
item.
5. If this item is reset, the asterisk will disappear.
(Setting cleared)
6. Press .
The setting for this parameter will appear on
the Reject Setting menu.
Figure 8-38 Reject Setting Menu
Figure 8-39 Zero Error Signal Signal Menu
ENTER

▼

▲

SELECT
ITEM
EXIT
[Reject Setting]
* Ext.1 Output Signal OFF
* Ext.2 Output Signal OFF
* Zero Error Signal OFF
[Zero Error Signal]
Signal No. : 1 2 3 4 5
Output Pattern :
No.5 : Reject Buzzer Signal
