11 OPTION DACS-W Operation Manual
11-22
11.4.3.7 Sample Count
This defines the number of packs from which to derive the average value. To set Sample Count follow
the procedures listed below.
11.4.3.8 Sample Interval
This defines the interval from when the first pack using a new pulse count is sent until it is check
weighted by DACS. Sampling is not taken during this interval. To set Sample Interval follow the
procedures listed below.
11.4.3.9 FB%
This defines the ratio for converting the amount of target weight and average sampled deviation into
pulse signal output (count or width). This value is different according to FB output type. To set FB%
note the differences according to type and follow.
1. Call up the FBC Setting menu.
2. Press and move the cursor to Sample
Count.
3. Set value via ten-keys.
The setting for Sample Count is complete.
Figure 11-54 FBC Setting Menu
1. Call up the FBC Setting menu.
2. Press and move the cursor to Sample
Interval.
3. Set value via ten-keys.
The setting for Sample Interval is complete.
Figure 11-55 FBC Setting Menu
For pulse count output: For pulse width output:
Sets weight for one pulse. Sets weight for one second
Setting : [65.535 g/s] or less Setting : [65.535 g/p] or less.
1. Call up the FBC Setting menu.
2. Press and move the cursor to FB%.
3. Set value via ten-keys.
The setting for FB% is complete.
Figure 11-56 FBC Setting Menu
ENTER
▼
* FBC Unused Range - 1.0 g
[FBC Setting]
* Sample Count 5
* Sample Interval 2
ENTER
▼
* FBC Unused Range - 1.0 g
[FBC Setting]
* Sample Count 5
* Sample Interval 2
ENTER
▼
[FBC Setting]
* Sample Interval 2
FB% 0.123 g/p
*
* Control Pulse freq 60 Hz
To Next Page
