DACS-W Operation Manual 8 ADDITIONAL FUNCTIONS
8-15
8.4.2.12 Metal Detection Output Signal
This item sets the output signal which is output when metal detected packs are passed.
Follow this procedure to set the signal parameter.
8.4.2.13 External 1 Output Signal
This item sets the signal to output when product is diverted to the predetermined direction by the external
input signal 1. This setting is required only when the external input signal 1 is used.
Follow this procedure to set the signal parameter.
1. Display the Reject Setting menu.
2. Press or to align the cursor with
"Metal Detection Signal".
3. Press .
The Metal Detection Signal menu appears.
4. Set the output signal via the ten-key pad.
An asterisk (*) will appear below the set
item.
5. If this item is reset, the asterisk will disappear.
(Setting cleared)
6. Press .
The setting for this parameter will appear on
the Reject Setting menu.
Figure 8-32 Reject Setting Menu
Figure 8-33 Metal Detection Signal Menu
ENTER
▼
▲
SELECT
ITEM
EXIT
[Reject Setting]
* Over Weight Signal 2
* Under Weight Signal OFF
* Metal Detection Signal OFF
[Metal Detection Signal]
Signal No. : 1 2 3 4 5
Output Pattern :
No.5 : Reject Buzzer Signal
To Next Page
