DACS-W Operation Manual 11 OPTION
11-27
11.6.3.2 Ok-Under Wt. Rej. Dir.
This sets the reject direction of Ok-Under Weight items. To set Ok-Under Wt. Rej. Dir. follow the
procedures listed below.
11.6.3.3 Ok-Over Wt. Signal
This sets the signal sent by Ok-Over Weight items when passing through DACS-W. To set the Ok-Over
Weight signal follow the procedures listed below.
1. Call up the Reject Setting menu.
2. Press and move the cursor to Ok-Under
Wt. Rej. Dir.
3. Press .
The Ok-Under Wt. Rej. Dir. menu appears.
4. Select left by entering 0 via the ten-key.
Select center by entering 1 via the ten-key.
Select right by entering 2 via the ten-key.
Select stop by entering 3 via the ten-key.
The setting for Ok-Under Wt. Rej. Dir. is
complete.
Figure 11-66 Reject Setting Menu
Figure 11-67 Ok-Under Wt. Rej. Dir. Selection Menu
1. Call up the Reject Setting menu.
2. Press and move the cursor to Ok-Over
Wt. Signal.
3. Press .
The Ok-Over Wt. Signal menu appears.
4. Set value via the ten-key.
An asterick (*) appears beneath the selected
item.
5. When the Ok-Over Wt. Signal is reset, the
asterick (*) disappears. (The setting is
cleared.)
The setting for Ok-Over Wt. Signal is
complete.
Figure 11-68 Reject Setting Menu
Figure 11-69 Ok-Over Wt. SIgnal Menu
ENTER

▼

SELECT
ITEM
[Reject Setting]
* Under Wt. Re. Dir. Left
* Ok-Over Wt. Rej. Dir Center
* Ok-Under Wt. Rej. Dir Center
[Ok-Under Wt. Rej. Dir]
0 ...left 2 ...right
1 ...center 3 ...stop
ENTER

▼

SELECT
ITEM
[Reject Setting]
* Under Weigh Signal 3
* Ok-Over Wt. SIgnal 1&B
* Ok-Under Wt. Signal 1&B
[Ok-Over Wt. SIgnal]
Output Signal :1 2 3 4 5
Output Pattern :
No.5 Reject Buzzer Signal
