11 OPTION DACS-W Operation Manual
11-20
11.4.3.2 FBC Target Weight
This defines the target net weight for packs filled by the auger filler. Feedback control is based on this
target weight. To set FBC Target Weight follow the procedures listed below.
11.4.3.3 Sample Range +
This defines the maximum pack weight above which the pack will not be included in the sampling. To
set Sampling Range + follow the procedures listed below.
1. Call up the Preset Setting menu.
2. Press and move the cursor to FBC.
3. Press .
4. Enter 0 via the ten-key to deactivate Feedback
Control.
Enter 1 via the ten-key to activate Feedback
Control.
The FBC Setting display appears.
Figure 11-47 FBC Setting Menu
Figure 11-48 FBC Settings
1. Call up the FBC Setting menu.
2. Press and move the cursor to FBC Target
Wt.
3. Set value via ten-keys.
The setting for FBC Target Weight is
complete.
Figure 11-49 FBC Setting Menu
1. Call up the FBC Setting menu.
2. Press and move the cursor to Sampling
Range +.
3. Set value via ten-keys.
The setting for Sampling Range + is
complete.
Figure 11-50 FBC Setting Menu
ENTER
▼
SELECT
ITEM
FBC
*
[FBC Setting]
ON
* FBC Target Wt. 250.0 g
* Sampling Range + 100.0 g
[FBC]
ON
0... OFF
1...
ENTER
▼
FBC
*
[FBC Setting]
ON
* FBC Target Wt. 250.0 g
* Sampling Range + 100.0 g
ENTER
▼
* Sampling Range + 100.0 g
* Sampling Range - 100.0 g
* FBC Unused Range + 1.0 g
[FBC Setting]
To Next Page
