8 ADDITIONAL FUNCTIONS DACS-W Operation Manual
8-16
8.4.2.14 External 2 Output Signal
This item sets the signal to output when product is diverted to the predetermined direction by the external
input signal 2. This setting is required only when the external input signal 2 is used.
Follow this procedure to set the signal parameter.
1. Display the Reject Setting menu.
2. Press or to align the cursor with
"Ext.1 Output Signal".
3. Press .
The Ext.1 Output Signal menu appears.
4. Set the output signal via the ten-key pad.
An asterisk (*) will appear below the set
item.
5. If this item is reset, the asterisk will disappear.
(Setting cleared)
6. Press .
The setting for this parameter will appear on
the Reject Setting menu.
Figure 8-34 Reject Setting Menu
Figure 8-35 Ext.1 Output Signal Menu
1. Display the Reject Setting menu.
2. Press or to align the cursor with
"Ext.2 Output Signal".
3. Press .
The Ext.2 Output Signal menu appears.
4. Set the output signal via the ten-key pad.
An asterisk (*) will appear below the set
item.
5. If this item is reset, the asterisk will disappear.
(Setting cleared)
6. Press .
The setting for this parameter will appear on
the Reject Setting menu.
Figure 8-36 Reject Setting Menu
Figure 8-37 Ext.2 Output Signal Menu
ENTER
SELECT
ITEM
EXIT
[Reject Setting]
* Under Weight Signal OFF
* Metal Detection Signal OFF
* Ext.1 Output Signal OFF
[Ext.1 Output Signal]
Signal No. : 1 2 3 4 5
Output Pattern :
No.5 : Reject Buzzer Signal
ENTER
SELECT
ITEM
EXIT
[Reject Setting]
* Metal Detection Signal OFF
* Ext.1 Output Signal OFF
* Ext.2 Output Signal OFF
[Ext.2 Output Signal]
Signal No. : 1 2 3 4 5
Output Pattern :
No.5 : Reject Buzzer Signal
