DACS-W Operation Manual 5 NORMAL OPERATIONS & FUNCTIONS
5-21
5.6.1.7 Timing Setting
The Timing Setting menu is used to adjust operational timing for checkweigher components to achieve
a smooth flow of product across the conveyors.
There are 12 setting items in this menu.
For descriptions of the timing setting parameters refer to Table 5-3.
Timing Setting data is registered as shown below.
1. Call up the Preset menu.
2. Press to scroll the cursor to "Timing
Setting".
3. Press .
The Timing Setting screen appears.
Figure 5-40 Preset Menu
4. Press or to align cursor with desired
setting items.
5. Enter the desired values via the ten-key pad.
The set value appears and the cursor moves
to the next item.
6. After all items have been set, press .
The Preset menu returns.
Figure 5-41 Timing Setting Menu (1)
Figure 5-42 Timing Setting Menu (2)
Figure 5-43 Timing Setting Menu (3)
Figure 5-44 Timing Setting Menu (4)
ENTER
▼
SELECT
ITEM
[Preset]
No. 2
* Product Name M
* Product Code 8
* Timing Setting
ENTER
▼
▲
EXIT
[Timing Setting]
* Feed Conv. Speed 20 m/min
* Weigh Conv. Speed 20 m/min
* Reject Conv.Speed 20 m/min
[Timing Setting]
* Reject Start Time 0 ms
* Reject ON Time 0 ms
* Metal Detect Delay 0 ms
[Timing Setting]
* Output Signal 1 Delay 0 ms
* Output Signal 2 Delay 0 ms
* Output Signal 3 Delay 0 ms
[Timing Setting]
* Output Signal 4 Delay 0 ms
* Ext. Input 1 Delay 0 ms
* Ext. Input 2 Delay 0 ms
To Next Page
