11 OPTION DACS-W Operation Manual
11-28
11.6.3.4 Ok-Under Wt. Signal
This sets the signal sent by Ok-Under Wt. Signal items when passing through DACS-W. To set the Ok-
Under Wt. Signal follow the procedures listed below.
11.6.4 System Configuration
An item was added to the System Configuration menu concerning Weighing Zone. To set the Weighing
Zone follow the procedures listed below.
1. Call up the Reject Setting menu.
2. Press and move the cursor to Ok-Under
Wt. Signal.
3. Press .
The Ok-Under Wt. Signal menu appears.
4. Set value via the ten-key.
An asterick (*) appears beneath the selected
item.
5. When the Ok-Under Wt. Signal is reset, the
asterick (*) disappears and the setting is
cleared.
The setting for Ok-Under Wt. Signal is
complete.
Figure 11-70 Reject Setting Menu
Figure 11-71 Ok-Under Wt. Signal Menu
1. Call up the System Configuration menu.
2. Press and move the cursor to Weighing
Zone.
3. Press .
The Weighing Zone menu appears.
4. Enter 0 via the ten-key when wanting to
activate 3 Zone.
Enter 1 via the ten-key when wanting to
activate 5 Zone.
The setting for Weighing Zone is complete
and is shown in the System Configuration
menu.
Figure 11-72 System Configuration Menu
Figure 11-73 Weighing Zone Menu
ENTER
▼
SELECT
ITEM
[Reject Setting]
* Under Weigh Signal 3
* Ok-Over Wt. SIgnal 1&B
* Ok-Under Wt. Signal 1&B
[Ok-Over Wt. SIgnal]
Output Signal :1 2 3 4 5
Output Pattern :
No.5 Reject Buzzer Signal
ENTER
▼
SELECT
ITEM
[System Configuration]
* Gap Control OFF
* Standard Revision ON
* Weighing Zone 5 zones
[Weighing Zone]
0 ...3 zones
1 ...5 zones
To Next Page
