5 NORMAL OPERATIONS & FUNCTIONS DACS-W Operation Manual
5-12
5.5.2 Preset Setting
Preset parameters (presets) which have been entered previously in the Site Engineer level can be called
up in the Operator level. [See "5.6.1 Preset Setting"]
Follow the procedure outlined below to call up a preset.
5.5.3 Changing the Access Level
For information on changing the access level, refer to Section "5.4 Access Level Change".
1. In the Production Standby menu, press .
The Operator Level Setup Menu appears.
2. Press .
The Preset Number menu appears.
Figure 5-15 Setup Menu (Level 0)
3. Enter the desired preset number via ten-key
pad.
The Operator level Setup Menu returns.
Figure 5-16 Preset Number Menu
4. Press .
The Production Standby menu for the
selected preset will appear.
• During operation presets can be entered via ten-key
pad or by aligning the cursor and pressing the
or key .
However, when the selected preset number is [0], a
preset number cannot be called up on the
ProductionStandby screen.
Figure 5-17 Setup Menu (Level 0)
Figure 5-18 Production Standby Menu
SET
UP
SELECT
ITEM
[Setup Menu]
* Preset 0
* Access Level Change Level 0
[Preset Number]
0: 80.0 Candy 4: 300.0 Chocolate
1: 90.0 Candy 5: 120.0 Chocolate
2: 100.0 Candy 6: 200.0 Gum
3: 100.0 Cookies 7: 150.0 Gum
Enter Preset Number
2
Preset No.
Reference Weight
Product Name
Selected Preset No,
EXIT
ENTER
▼
▲
[Setup Menu]
* Preset 2
* Access Level Change Level 0
No.2 Candy
0.0
g
REF WT 100.0 g
UPPER+ 1.0 g
LOWER- 1.0 g
To Next Page
