11.1.3.4 Sample Range +
This defines the maximum pack weight above which the pack will not be included in the sampling. To
set Sampling Range + follow the procedures listed below.
11.1.3.5 Sample Range -
This defines the minimum pack weight below which the pack will not be included in the sampling. To
set Sampling Range - follow the procedures listed below.
11.1.3.6 FBC Unused Range +
This defines the average weight value which activates FBC when this weight is exceeded. To set FBC
Unused Range + follow the procedures listed below.
1. Call up the FBC Setting menu.
2. Press and move the cursor to FBC Target
Wt.
3. Set value via ten-keys.
The setting for FBC Target Weight is
complete.
Figure 11-8 FBC Setting Menu
1. Call up the FBC Setting menu.
2. Press and move the cursor to Sampling
Range +.
3. Set value via ten-keys.
The setting for Sampling Range + is
complete.
Figure 11-9 FBC Setting Menu
1. Call up the FBC Setting menu.
2. Press and move the cursor to Sampling
Range -.
3. Set value via ten-keys.
The setting for Sampling Range - is
complete.
Figure 11-10 FBC Setting Menu
ENTER

▼

FBC
*
* Control Pulse
* FBC Target Wt. 250.0 g
[FBC Setting]
ON
200
ENTER

▼

* Sampling Range + 100.0 g
* Sampling Range - 100.0 g
* FBC Unused Range + 1.0 g
[FBC Setting]
ENTER

▼

* Sample Range + 100.0 g
* Sample Range - 100.0 g
* FBC Unused Range + 1.0 g
[FBC Setting]
