DACS-W Operation Manual 11 OPTION
11-3
To set FBC follow the procedures listed below.
11.1.3.2 Control Pulse
This defines the number of auger filler pulse signals at which the Auger ON signal will be terminated.
By increasing/decreasing the value, auger fill amount is correspondingly increased/decreased.
Setting:This item should be set to a value of 50,000 or less.
To set Control Pulse follow the procedures listed below.
11.1.3.3 FBC Target Weight
This defines the target net weight for packs filled by the auger filler. Feedback control is based on this
target weight. To set FBC Target Weight follow the procedures listed below.
1=ON: Auger filler is controlled by a pulse count continuously reset according to
weighing results.
1. Call up the Preset Setting menu.
2. Press and move the cursor to FBC
Setting.
3. Press .
4. Enter 0 via the ten-key to deactivate Feedback
Control.
Enter 1 via the ten-key to activate Feedback
Control.
The FBC Setting display appears.
Figure 11-5 FBC Setting Menu
Figure 11-6 FBC Settings
1. Call up the FBC Setting menu.
2. Press and move the cursor to Control
Pulse.
3. Set value via ten-keys.
The setting for Control Pulse is complete.
Figure 11-7 FBC Setting Menu
ENTER
▼
SELECT
ITEM
FBC
*
* Control Pulse
* FBC Target Wt. 250.0 g
[FBC Setting]
ON
200
[FBC]
ON
0... OFF
1...
ENTER
▼
FBC
*
* Control Pulse
* FBC Target Wt. 250.0 g
[FBC Setting]
ON
200
To Next Page
