2 INTRODUCTION DACS-W Operation Manual
2-2
2.2 Terminology
Some of the special terms used in this manual are explained below.
2.3 Model Specifications
Specifications by model are shown in the table below.
Table 2-1 Terminology
Term Definition
Product The article which is being checkweighed.
Packer The upstream equipment feeds product to the checkweigher.
Span After zero adjustment is performed, a standard span counterweight is weighed and the
measured value is stored in memory as a reference point for weighing.
Over (weight) Measured weight of product exceeds upper limit.
Under (weight) Measured weight of product is less than lower limit.
Proper (weight) Measured weight of product is within the range between upper and lower limit values.
Table 2-2 Model Specifications
Item Specification
Model Name DACS-W-003 DACS-W-012 DACS-W-030 DACS-W-050
Capacity 300g 1200g 3000g 5000g
Span Weight 300g 1kg 3kg 5kg
Minimum Grad. 0.1g 0.1g 0.5g 1g
