Model 2651A High Power System SourceMeter® Instrument Reference Manual Section 2: General operation
2651A-901-01 Rev. A / March 2011 2-17
The following table contains descriptions of the main menu items, as well as cross-references to
related information. To access a menu item, press the MENU key, turn the navigation wheel
to
move the cursor to select the desired item, and press the navigation wheel
.
Menu selection Description For more information,
see:
SCRIPT Saves and recalls users scripts Manage scripts (on page
6-3)
- LOAD Loads scripts into nonvolatile memory
- SAVE Saves scripts
SETUP Saves and recalls user and factory setup options User setup (on page 2-39)
- SAVE Saves user setup options
- RECALL Recalls user setup options
- POWERON Sets the configuration used during startup
GPIB Configures the GPIB interface options Communications
Interfaces (on page 2-73)
- ADDRESS Configures the address for the GPIB interface
- ENABLE Enables and disables the GPIB interface
LAN Configures the local area network (LAN) LAN concepts and settings
(on page C-1)
- STATUS Displays LAN connection status
- CONFIG Configures the LAN IP address and gateway
- APPLY_SETTINGS Applies changes made using the CONFIG menu
- RESET Restores the default settings
- ENABLE Enables and disables the LAN interface
RS232 Controls the options for the RS-232 interface Communications
Interfaces (on page 2-73)
- BAUD Sets the baud rate
- BITS Configures the number of bits
- PARITY Sets the parity
- FLOW-CTRL Configures the flow control
- ENABLE Enables and disables the RS-232 interface
TSPLINK Configure the instrument in a TSP-Link
®
network TSP-Link system
expansion interface (on
page 6-47)
- NODE Selects the instrument node identifier
- RESET Resets the TSP-Link network
UPGRADE Upgrades the firmware from a USB flash drive Upgrading the firmware
(on page A-4)
DISPLAY Accesses display functions Front panel tests (on page
A-2)
- TEST Runs the display test See Numeric entry method
in Setting a value
(on page
2-20)
- NUMPAD Enables and disables the numeric keypad
DIGOUT Controls digital outputs Digital I/O (on page 3-83)
- DIG-IO-OUTPUT Selects the digital I/O values
- WRITE-PROTECT Write-protects specific digital I/O lines
BEEPER Controls the key beeps General operation (on
page 2-1)
- ENABLE Enables the key beeps
- DISABLE
Disables the key beeps
