Stop category 1 –
Drive Ramp Stop
The manipulator and any external axes (optional) perform path-ori-
ented braking.
• Operating mode T1: the drives are deactivated as soon as the
robot has stopped, but no later than after 680 ms.
• Operating modes T2, AUT (KR C controller), AUT EXT (KR C
controller), EXT (VKR C controller):
The drives are switched off after 1.5 s.
Note: This stop category is called STOP 1 - DRS in this document.
Stop category 2 The drives are not deactivated and the brakes are not applied. The
manipulator and any external axes (optional) are braked with a
path-maintaining braking ramp.
Note: This stop category is called STOP 2 in this document.
System integrator
(plant integrator)
The system integrator is responsible for safely integrating the indus-
trial robot into a complete system and commissioning it.
T1 Test mode, Manual Reduced Velocity (<= 250 mm/s)
T2 Test mode, Manual High Velocity (> 250 mm/s permissible)
External axis Motion axis which is not part of the manipulator but is controlled by
the robot controller, e.g. KUKA linear unit, turn-tilt table, positioner.
3.2 Personnel
The following persons or groups of persons are defined for the industrial
robot:
• User
• Personnel
Qualification of personnel
Work on the system must only be performed by personnel that is able
to assess the tasks to be carried out and detect potential hazards.
Death, severe injuries or damage to property may otherwise result. The
following qualifications are required:
• Adequate specialist training, knowledge and experience
• Knowledge of the relevant operating or assembly instructions, knowl-
edge of the relevant standards
• All persons working with the industrial robot must have read and un-
derstood the industrial robot documentation, including the safety
chapter.
User
The user must observe the labor laws and regulations. This includes e.g.:
• The user must comply with his monitoring obligations.
• The user must carry out briefing at defined intervals.
• The user must comply with the regulations relating to personal protec-
tive equipment (PSA).
Personnel
Personnel must be instructed, before any work is commenced, in the type
of work involved and what exactly it entails as well as any hazards which
KR IONTEC
22/344 | www.kuka.com MA KR IONTEC V4 | Issued: 11.05.2021
Safety
