Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1-1
1-3-38
U051 [LSU Out Top B/W]
Change in value per step: 1.0 mm
(L): When large size paper is used (218 mm or more in width of paper).
(S): When small size paper is used.
[LSU Out Top 3/4]
Change in value per step: 1.0 mm
(L): When large size paper is used (218 mm or more in width of paper).
(S): When small size paper is used.
2. Change the setting value using the numeric keys.
For output example 1, increase the value. For output example 2, decrease the value.
The greater the value, the larger the deflection; the smaller the value, the smaller the deflec-
tion.
Figure 1-3-6
3. Press the OK key. The value is set.
Completion
Press the Back key. The indication for selecting a maintenance item No. appears.
Item No. Description
Display Description
Setting
range
Initial setting
45ppm 55ppm
MPT(L) Paper feed from MP tray -30 to 20 - -8
Cass(L) Paper feed from cassette -30 to 20 - -8
Dup(L) Duplex mode (second) -30 to 20 - -8
MPT(S) Paper feed from MP tray -30 to 20 - -8
Cass(S) Paper feed from cassette -30 to 20 - -8
Dup(S) Duplex mode (second) -30 to 20 - -8
Display Description
Setting
range
Initial setting
45ppm 55ppm
MPT(L) Paper feed from MP tray -30 to 20 -2 -2
Cass(L) Paper feed from cassette -30 to 20 -2 -2
Dup(L) Duplex mode (second) -30 to 20 -2 -2
MPT(S) Paper feed from MP tray -30 to 20 -2 -2
Cass(S) Paper feed from cassette -30 to 20 -3 -3
Dup(S) Duplex mode (second) -30 to 20 -2 -2
Print
example 1
Print
example 2
