2MN/2N1-1
1-3-48
U089 Outputting a MIP-PG pattern
Description
Selects and outputs the MIP-PG pattern created in the machine.
Purpose
To check machine status when adjusting image printing, using MIP-PG pattern output.
Method
1. Press the OK key.
2. Select the MIP-PG pattern to be output and press the OK key.
3. Press the menu key.
4. Press the OK key. A MIP-PG pattern is output.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description Purpose
256Gradation 256-gradation PG To check the gradation reproducibility
Color Belt Four color belts PG To check the developer state and the
engine section ID
Gray(C) Cyan PG To check the drum quality
Gray(M) Magenta PG To check the drum quality
Gray(Y) Yellow PG To check the drum quality
Gray(K) Black PG To check the drum quality
White Blank paper PG To check the drum quality
Gradation Gray 5-graduation gray PG To check for vertical lines on the laser
scanner unit
Sample Set Four color belts PG,
Cyan PG, Magenta PG,
Yellow PG and Black PG
Pattern output for LLU assurance
application
