2MN/2N1
1-3-30
U032 Checking the operation of the clutches
Description
Turns each clutch on.
Purpose
To check the operation of each clutch.
Method
1. Press the OK key.
2. Select [Motor On] or [Motor Off].
3. Press the OK key.
4. Select the clutch to be operated.
5. Press the OK key. The operation starts.
6. To stop operation, press the Back key.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Motor On
Motor is turned on
Motor Off
Motor is turned off
Display Description
Feed1 Paper feed clutch 1 (PFCL1) is turned on
Feed2 Paper feed clutch 2 (PFCL2) is turned on
MPT Feed MP paper feed clutch (MPPFCL) is turned on
Feed Paper conveying clutch (PCCL) is turned on
Assist1 Assist clutch 1 (ASCL1) is turned on
Assist2 Assist clutch 2 (ASCL2) is turned on
